混凝土坍落度Slump of concrete mm 70-260

液壓傳動系統Hydraulic Power Transmission System

油泵型號Pump model CBGV-4025

馬達型號Hydraulic motor model BMSS-250

減速機速比Reducer ratio 01：10

供水系統Water Supply

水箱容量/供水形式Tank capacity/ water supply form L 540/自帶式自動訂時自動常通供水機構

540/ automatic timing water supply mechanism with automatic timing

底盤主要性能參數發動機主要性能參數The main performance parameters of the chassis and the main performance parameters of the engine

發動機型號/排量Engine type / displacement L CF4B68G-Z-13B2/CF4C100T-Z-13B2

形式model 直噴式四沖程水冷增壓柴油機

Straight injection type four stroke water cooled supercharged diesel engine

額定功率Rated power kw/r/min 55KW/2400 78KW/2400

樶大扭矩  torque N.m/r/min 255/1500-1800 380/1500-1800

樶大行駛速度  running speed km/h 24

樶小轉彎半徑Min steering radius mm 5000

爬坡能力Climbing capacity % 26

輪胎Tire 23.5/70-16

驅動形式Driving way 4×4

整車裝備質量Weight kg 4580

樶大裝載質量 imum load capacity kg 2800

樶大車輛總質量Whole machinery weight kg 7380

整車外形尺寸（長*寬*高）Overall size(L*W*H) mm 6100*1850*3000
