迷你型氣控閥
| 迷你型常開氣控閥（Normally Open，彈簧打開/供氣關閉) | ||
| 閥門系列 | 最大工作壓力 | 關閉閥座所需的大致空氣壓力 |
| 10-**AF2 | 6,000 psi | 55 psi |
| 10-**AF4 | 6,000 psi | 55 psi |
| 10-**AF6 | 6,000 psi | 55 psi |
| 30-**HF4 | 6,000 psi | 55 psi |
| 30-**HF6 | 6,000 psi | 55 psi |
| 30-**HF9 | 6,000 psi | 55 psi |
| 迷你型常閉氣控閥（Normally Closed，供氣打開/彈簧關閉) | ||||
| 閥門系列 | 最大工作壓力 | 最小調節螺栓力矩 | 打開閥座所需的大致空氣壓力 | 打開全部閥座所需的大致空氣壓力 |
| 10-**AF4 | 6,000 psi | 15 in.ib | 55 psi | 90 psi |
| 10-**AF6 | 6,000 psi | 15 in.ib | 55 psi | 90 psi |
| 30-**HF4 | 6,000 psi | 15 in.ib | 55 psi | 90 psi |
| 30-**HF6 | 6,000 psi | 15 in.ib | 55 psi | 90 psi |
| 30-**HF9 | 6,000 psi | 15 in.ib | 55 psi | 90 psi |
| 備注：**代表手動針閥系列型號代號，有關手動針閥型號請參見高壓針閥。 | ||||
膜片式氣控閥
| 常開氣控閥（Normally Open，彈簧打開/供氣關閉) | ||
| 閥門系列 | 最大工作壓力 | 打開閥座所需的大致 空氣壓力 |
| 10-**AF4 | 10,000 psi | 35 psi |
| 10-**AF6 | 10,000 psi | 35 psi |
| 10-**NFA | 10,000 psi | 35 psi |
| 10-**NFB | 10,000 psi | 35 psi |
| 10-**NFC | 10,000 psi | 35 psi |
| 15F-**NFA | 15,000 psi | 85 psi |
| 15F-**NFB | 15,000 psi | 85 psi |
| 15F-**NFC | 10,000 psi | 100 psi |
| 15F-**NFD | 10,000 psi | 100 psi |
| 20-**LF4 | 20,000 psi | 60 psi |
| 20-**LF6 | 15,000 psi | 85 psi |
| 20-**LF9 | 10,000 psi | 100 psi |
| 30-**HF4 | 30,000 psi | 60 psi |
| 30-**HF6 | 30,000 psi | 85 psi |
| 30-**HF9 | 30,000 psi | 85 psi |
| 40-**HF9 | 30,000 psi | 85 psi |
| 60-**HF4 | 60,000 psi | 70 psi |
| 60-**HF6 | 60,000 psi | 70 psi |
| 60-**HF9 | 60,000 psi | 70 psi |
| 常閉氣控閥（Normally Closed，供氣打開/彈簧關閉) | ||||
| 閥門系列 | 最大工作壓力 | 最小調節螺栓力矩 | 打開閥座所需的大致空氣壓力 | 打開全部閥座所需的大致空氣壓力 |
| 10-**AF4 | 10,000 psi | 20 in.lb | 30 psi | 45 psi |
| 10-**AF6 | 10,000 psi | 20 in.lb | 30 psi | 45 psi |
| 10-**NFA | 10,000 psi | 20 in.lb | 30 psi | 45 psi |
| 10-**NFB | 10,000 psi | 20 in.lb | 30 psi | 45 psi |
| 10-**NFC | 10,000 psi | 20 in.lb | 30 psi | 45 psi |
| 15F-**NFA | 15,000 psi | 60 in.lb | 80 psi | 100 psi |
| 15F-**NFB | 15,000 psi | 60 in.lb | 80 psi | 100 psi |
| 15F-**NFC | 10,000 psi | 75 in.lb | 95 psi | 100 psi |
| 15F-**NFD | 10,000 psi | 75 in.lb | 95 psi | 100 psi |
| 20-**LF4 | 20,000 psi | 40 in.lb | 55 psi | 90 psi |
| 20-**LF6 | 15,000 psi | 60 in.lb | 80 psi | 100 psi |
| 20-**LF9 | 10,000 psi | 75 in.lb | 95 psi | 100 psi |
| 30-**HF4 | 30,000 psi | 40 in.lb | 55 psi | 75 psi |
| 30-**HF6 | 30,000 psi | 60 in.lb | 80 psi | 100 psi |
| 30-**HF9 | 30,000 psi | 60 in.lb | 80 psi | 100 psi |
| 40-**HF9 | 30,000 psi | 60 in.lb | 80 psi | 100 psi |
| 60-**HF4 | 60,000 psi | 50 in.lb | 65 psi | 85 psi |
| 60-**HF6 | 60,000 psi | 50 in.lb | 65 psi | 85 psi |
| 60-**HF9 | 60,000 psi | 50 in.lb | 65 psi | 85 psi |
| 備注：**代表手動針閥系列型號代號，有關手動針閥型號請參見高壓針閥。 | ||||
中載型/重載型/超重載型氣控閥
| 中載型/重載型/超重載型常閉氣控閥（Normally Closed，供氣打開/彈簧關閉) | ||||||
| 中載型 | ||||||
| 閥門系列 | 最大工作壓力 | 節流口通直徑 (通徑) | 最小調節螺栓力矩 | 打開閥座所需的大致空氣壓力 | 打開全部閥座所需的大致空氣壓力 | 型號后綴 |
| 10-**AF4 | 10,000 psi | 1/8" | 25 in.lb | 30 psi | 40 psi | MPO-NC |
| 10-**AF6 | 10,000 psi | 1/8" | 25 in.lb | 30 psi | 40 psi | MPO-NC |
| 15F-**NFA | 15,000 psi | 13/64" | 45 in.lb | 55 psi | 75 psi | MPO-NC |
| 15F-**NFB | 15,000 psi | 13/64" | 45 in.lb | 55 psi | 75 psi | MPO-NC |
| 15F-**NFC | 10,000 psi | 5/16" | 55 in.lb | 70 psi | 95 psi | MPO-NC |
| 15F-**NFD | 10,000 psi | 5/16" | 55 in.lb | 70 psi | 95 psi | MPO-NC |
| 20-**LF4 | 20,000 psi | 1/8" | 50 in.lb | 70 psi | 95 psi | MPO-NC |
| 20-**LF6 | 15,000 psi | 13/64" | 55 in.lb | 70 psi | 95 psi | MPO-NC |
| 20-**LF9 | 10,000 psi | 5/16" | 55 in.lb | 70 psi | 95 psi | MPO-NC |
| 30-**HF4 | 30,000 psi | 3/32" | 50 in.lb | 60 psi | 75 psi | MPO-NC |
| 30-**HF6 | 30,000 psi | 1/8" | 55 in.lb | 60 psi | 75 psi | MPO-NC |
| 30-**HF9 | 30,000 psi | 1/8" | 55 in.lb | 60 psi | 75 psi | MPO-NC |
| 60-**HF4 | 60,000 psi | 1/16" | 50 in.lb | 50 psi | 65 psi | MPO-NC |
| 60-**HF6 | 60,000 psi | 1/16" | 50 in.lb | 50 psi | 65 psi | MPO-NC |
| 60-**HF9 | 60,000 psi | 1/16" | 50 in.lb | 50 psi | 65 psi | MPO-NC |
| 重載型 | ||||||
| 15F-**NFC | 15,000 psi | 5/16" | 85 in.lb | 60 psi | 75 psi | HPO-NC |
| 15F-**NFD | 15,000 psi | 5/18" | 85 in.lb | 60 psi | 75 psi | HPO-NC |
| 20-**LF4 | 20,000 psi | 1/8" | 55 in.lb | 35 psi | 50 psi | HPO-NC |
| 20-**LF6 | 20,000 psi | 13/64" | 60 in.lb | 35 psi | 50 psi | HPO-NC |
| 20-**LF9 | 16,000 psi | 5/16" | 85 in.lb | 60 psi | 75 psi | HPO-NC |
| 20-**LF12 | 9,000 psi | 7/18" | 85 in.lb | 60 psi | 75 psi | HPO-NC |
| 20-**LF16 | 6,000 psi | 9/16" | 85 in.lb | 60 psi | 75 psi | HPO-NC |
| 30-**HF4 | 30,000 psi | 3/32" | 50 in.lb | 30 psi | 40 psi | HPO-NC |
| 30-**HF6 | 30,000 psi | 1/8" | 55 in.lb | 30 psi | 40 psi | HPO-NC |
| 30-**HF9 | 30,000 psi | 1/8" | 55 in.lb | 30 psi | 40 psi | HPO-NC |
| 60-**HF4 | 60,000 psi | 1/16" | 50 in.lb | 25 psi | 35 psi | HPO-NC |
| 60-**HF6 | 60,000 psi | 1/16" | 50 in.lb | 25 psi | 35 psi | HPO-NC |
| 60-**HF9 | 60,000 psi | 1/16" | 50 in.lb | 25 psi | 35 psi | HPO-NC |
| 超重載型 | ||||||
| 20-**LF12 | 20,000 psi | 7/16" | 60 in.lb | 35 psi | 60 psi | EHPO-NC |
| 10-**NFF | 10,000 psi | 11/16" | 75 in.lb | 45 psi | 70 psi | EHPO-NC |
| 10-**NFH | 10,000 psi | 11/16" | 75 in.lb | 45 psi | 70 psi | EHPO-NC |
| 10-**LF16 | 10,000 psi | 11/16" | 75 in.lb | 45 psi | 70 psi | EHPO-NC |
| 20-**LF16 | 20,000 psi | 9/16" | 95 in.lb | 55 psi | 95 psi | EHPO-NC |
| 30-**LF16 | 30,000 psi | 7/16" | 90 in.lb | 50 psi | 85 psi | EHPO-NC |
| 中載型/重載型/超重載型常開氣控閥（Normally Open，彈簧打開/供氣關閉) | ||||
| 中載型 | ||||
| 閥門系列 | 最大工作壓力 | 節流口直徑 (通徑) | 打開閥座所需的大致空氣壓力 | 型號后綴 |
| 10-**AF4 | 10,000 psi | 1/8" | 35 psi | MPO-NO |
| 10-**AF6 | 10,000 psi | 1/8" | 35 psi | MPO-NO |
| 15F-**NFA | 15,000 psi | 13/64" | 75 psi | MPO-NO |
| 15F-**NFB | 15,000 psi | 13/64" | 75 psi | MPO-NO |
| 15F-**NFC | 10,000 psi | 5/16" | 100 psi | MPO-NO |
| 15F-**NFD | 10,000 psi | 5/16" | 100 psi | MPO-NO |
| 20-**LF4 | 20,000 psi | 1/8" | 95 psi | MPO-NO |
| 20-**LF6 | 20,000 psi | 13/64" | 100 psi | MPO-NO |
| 20-**LF9 | 10,000 psi | 5/16" | 100 psi | MPO-NO |
| 20-**LF12 | 6,000 psi | 7/16" | 100 psi | MPO-NO |
| 30-**HF4 | 30,000 psi | 3/32" | 60 psi | MPO-NO |
| 30-**HF6 | 30,000 psi | 1/8" | 60 psi | MPO-NO |
| 30-**HF9 | 30,000 psi | 1/8" | 60 psi | MPO-NO |
| 60-**HF4 | 60,000 psi | 1/16" | 55 psi | MPO-NO |
| 60-**HF6 | 60,000 psi | 1/16" | 55 psi | MPO-NO |
| 60-**HF9 | 60,000 psi | 1/16" | 55 psi | MPO-NO |
| 重載型 | ||||
| 15F-**NFC | 15,000 psi | 5/16" | 75 psi | HPO-NO |
| 15F-**NFD | 15,000 psi | 5/16" | 75 psi | HPO-NO |
| 20-**LF4 | 20,000 psi | 1/8" | 55 psi | HPO-NO |
| 20-**LF6 | 20,000 psi | 13/64" | 55 psi | HPO-NO |
| 20-**LF9 | 20,000 psi | 5/16" | 95 psi | HPO-NO |
| 20-**LF12 | 13,000 psi | 7/16" | 100 psi | HPO-NO |
| 20-**LF16 | 8,800 psi | 9/16" | 100 psi | HPO-NO |
| 30-**HF4 | 30,000 psi | 3/32" | 35 psi | HPO-NO |
| 30-**HF6 | 30,000 psi | 1/8" | 35 psi | HPO-NO |
| 30-**HF9 | 30,000 psi | 1/8" | 35 psi | HPO-NO |
| 60-**HF4 | 60,000 psi | 1/16" | 30 psi | HPO-NO |
| 60-**HF6 | 60,000 psi | 1/16" | 30 psi | HPO-NO |
| 60-**HF9 | 60,000 psi | 1/16" | 30 psi | HPO-NO |
| 超重載型 | ||||
| 20-**LF12 | 20,000 psi | 7/16" | 55 psi | EHPO-NO |
| 10-**NFF | 10,000 psi | 11/16" | 45 psi | EHPO-NO |
| 10-**NFH | 10,000 psi | 11/16" | 45 psi | EHPO-NO |
| 10-**LF16 | 10,000 psi | 11/16" | 45 psi | EHPO-NO |
| 20-**LF16 | 20,000 psi | 9/16" | 55 psi | EHPO-NO |
| 30-**LF16 | 30,000 psi | 7/16" | 50 psi | EHPO-NO |
| 備注：**代表手動針閥系列型號代號，有關手動針閥型號請參見高壓針閥。 | ||||
遠程控制氣控閥
| 遠程控制常開氣控閥（Normally Open，彈簧打開/供氣關閉) | ||||||
| 閥門系列 | 最大工作 壓力 | 打開閥座所需的大致空氣 壓力 | 節流孔直徑（通徑） | 連接形式 | 鋼管規格 | |
| 外徑 | 內徑 | |||||
| D10R12LF9R | 10,000 psi | 60 psi | 1/4" | LF9 | 9/16" | 5/16" |
| D20R12LF9R | 20,000 psi | 75 psi | 1/4" | LF9 | 9/16" | 5/16" |
| D30R12HF4R | 30,000 psi | 65 psi | 1/8" | HF4 | 1/4" | 0.083" |
| D30R12HF6R | 30,000 psi | 65 psi | 1/8" | HF6 | 3/8" | 1/8" |
| D30R12HF9R | 30,000 psi | 65 psi | 1/8" | HF9 | 9/16" | 3/16" |
| D10R12HF9R | 10,000 psi | 60 psi | 1/4" | HF9 | 9/16" | 5/16" |
| D60R12HF4R | 60,000 psi | 55 psi | 1/16" | HF4 | 1/4" | 1/16" |
| D60R12HF6R | 60,000 psi | 55 psi | 1/16" | HF6 | 3/8" | 1/8" |
| D60R12HF9R | 60,000 psi | 55 psi | 1/16" | HF9 | 9/16" | 3/16" |
| D100R12XF4R | 100,000 psi | 90 psi | 1/16" | XF4 | 1/4" | 1/16" |
| D100R12XF6R | 100,000 psi | 90 psi | 1/16" | XF6 | 3/8" | 1/16" |
| 遠程控制常閉氣控閥（Normally Closed，供氣打開/彈簧關閉) | ||||||||
| 閥門系列 | 最大工作壓力 | 螺緊螺母 力矩 | 打開閥座所需的大致空氣壓力 | 打開全部閥座所需的大致空氣壓力 | 節流口直徑 (通徑) | 連接形式 | 鋼管規格 | |
| 外徑 | 內徑 | |||||||
| S10R12LF9R | 10,000 psi | 20 ft.ib. | 55 psi | 90 psi | 1/4" | LF9 | 9/16" | 5/16" |
| S20R12LF9R | 20,000 psi | 40 ft.ib. | 70 psi | 75 psi | 1/4" | LF9 | 9/16" | 5/16" |
| S30R12HF4R | 30,000 psi | 20 ft.ib. | 60 psi | 75 psi | 1/8" | HF4 | 1/4" | 0.083" |
| S30R12HF6R | 30,000 psi | 20 ft.ib. | 60 psi | 75 psi | 1/8" | HF6 | 3/8" | 1/8" |
| S30R12HF9R | 30,000 psi | 20 ft.ib. | 60 psi | 75 psi | 1/8" | HF9 | 9/16" | 3/16" |
| S10R12HF9R | 10,000 psi | 20 ft.ib. | 55 psi | 90 psi | 1/4" | HF9 | 9/16" | 5/16" |
| S60R12HF4R | 60,000 psi | 20 ft.ib. | 50 psi | 65 psi | 1/16" | HF4 | 1/4" | 1/16" |
| S60R12HF6R | 60,000 psi | 20 ft.ib. | 50 psi | 65 psi | 1/16" | HF6 | 3/8" | 1/8" |
| S60R12HF9R | 60,000 psi | 20 ft.ib. | 50 psi | 65 psi | 1/16" | HF9 | 9/16" | 3/16" |
| S100R12XF4R | 100,000 psi | 30 ft.ib. | 85 psi | 100 psi | 1/16" | XF4 | 1/4" | 1/16" |
| S100R12XF6R | 100,000 psi | 30 ft.ib. | 85 psi | 100 psi | 1/16" | XF6 | 3/8" | 1/16" |
